Demag System 1300/1500-11500
| Offer from: | 2026-08-25 |
| Categorie: | Injection moulding machines |
| Manufact./Type: | System 1300/1500-11500 |
| Price: | n.a. |
Technical data:
| Build in: | 2007 |
Photos:
Description:
Clamping force: 1300 t
Year of construction: 2007
Injection unit: .../11500
Screw diameter: 110 mm
Spec. injection pressure: 1971 bar
Injection volume: 5797 ccm
Shot weight in PS: 5200 g
L/D screw ratio: 24
Clamping unit: 1300/...
Platen size: 2150 x 1880 mm
Tie-bar clearance: 1500 x 1250 mm
Mould height: 700 - 1400 mm
Opening stroke: 1500 mm
Max. daylight: 2900 mm
Ejector force: 233 kN
Ejector stroke: 350 mm
Total connected load: 189 kW
Weight: 86700 kg
Control type: NC4
Equipment: 4 x hydraulic core pull, 12 hydraulic cascades, 32 hot runner zones, robot Wittmann DR 853 (year 2014) included
Year of construction: 2007
Injection unit: .../11500
Screw diameter: 110 mm
Spec. injection pressure: 1971 bar
Injection volume: 5797 ccm
Shot weight in PS: 5200 g
L/D screw ratio: 24
Clamping unit: 1300/...
Platen size: 2150 x 1880 mm
Tie-bar clearance: 1500 x 1250 mm
Mould height: 700 - 1400 mm
Opening stroke: 1500 mm
Max. daylight: 2900 mm
Ejector force: 233 kN
Ejector stroke: 350 mm
Total connected load: 189 kW
Weight: 86700 kg
Control type: NC4
Equipment: 4 x hydraulic core pull, 12 hydraulic cascades, 32 hot runner zones, robot Wittmann DR 853 (year 2014) included
