Clamping force kN: 1500
Size of mould platens ( h x v ) mm: 780 x 790
Distance between tie bars ( h x v ) mm: 500 x 500
Mould opening stroke mm: 600
Mould height min. mm: 300
Max. daylight mm: 900
Ejector stroke mm: 150
Screw diameter 1 mm: 50
L/D ratio 1: 20
Injection pressure 1 bar: 1892
Stroke volume 1 cm3: 377
Screw diameter 2 mm: 30
L/D ratio 2: 23
Injection pressure 2 bar: 2025
Stroke volume 2 cm3: 74
Control version: MC4
Screen text: Germany
Condition: Checked, ready to work
Equipment:
- Anti-vibration levelling pads
- Wear resistant plasticizer, surcharge
- Pneumatic valve 1 on moving platen for blow function
- Pneumatic valve 1 on fixed platen for blow function
- Mechanical robot interface according to EUROMAP 18
- Hydraulic core pull system 1-fold on moving platen
- Water battery 8-fold
- Signal interface for handling unit acc. to EUROMAP 12
