Year of Manufacture: 2013

Included Robot: Wittmann W832-0649

Injection Unit
Clamping force [kN]: 7000

Specific injection pressure [bar]: 1580

Screw diameter [mm] (mixing screw): 80

Max. shot volume [cm³]: 1860

Max. shot weight (PS) [g]: 1692.6

Max. screw speed [rpm]: 200

Max. plasticizing rate (PS) [g/s]: 76.8

Cylinder heating capacity [kW]: 38.35

Clamping Unit
Mould height (min.–max.) [mm]: 400–940

Tie bar spacing [mm]: 940 x 960

Opening stroke [mm]: 970

Centering diameter [mm] (moving/fixed platen): 200 / 200

Ejector stroke [mm] (stroke / through): 260 / 200

Equipment
Core pulls:

Moving platen: 2 units

Fixed platen: 2 units

Robot – Wittmann W832-0649
X-axis stroke [mm]: 900

Y-axis stroke [mm]: 1600

Z-axis stroke [mm]: 3000

Max. payload [kg]: 22

Robot weight [kg]: 545

Year of manufacture: 2013

Head axes: B servo + C90 pneumatic

Input axes: 2

Number of vacuum circuits: 3

Number of bistable valves: 4

Base height [mm]: 900

Adapter dimensions [mm x mm]: 160 x 160
